Industrial Nickel Metal Hydride (NiMH) Batteries
The Small Battery Company is the approved UK based distributor and retailer of a broad range of industrial Nickel Metal Hydride (NiMH) cells. These rechargeable Ni-MH cells are of high reliability, rapid charge, excellent discharge performance, long service life and wide temperature range. Typical fields of application field are: cordless phone, cellular phone, two way radio, R/C toys, emergency lightening and so on.
A range of beautifully engineered and Nickel Metal Hydride (NiMH) cells boasting the following characteristics:
- Ni-MH cells features the same voltage (1.2V) as Ni-CD, yet twice the capacity.
- Wide operational temperature range from -10°C to 50°C.
- Self-discharge is minimized to levels below Ni-CD for enhanced storage characteristics.
- Quick charging in about one hour is possible with a specially designed.
- Excellent Leakage Resistance and excellent Long-term Reliability.
Cylindrical tagged cells (Industrial Ni-MH)
|
1.2V, 1800 mAh, impedance 25 mOhm, up to 1000 cycles, weight 29.0 g, diameter 14.0 mm, height 50.0 mm. | ||
|---|---|---|
|
NH-AA1800_tag Price: £3.50 | |
|
1.2V, 2500 mAh, impedance 80 mOhm, up to 1000 cycles, weight 50.0 g, diameter 23 mm, height 43 mm. | ||
|---|---|---|
|
NH-SC2500_tag Price: £3.10 | |
|
1.2V, 800 mAh, impedance 30 mOhm, up to 1000 cycles, weight 13.0 g, diameter 11 mm, height 44 mm. | ||
|---|---|---|
|
NH-AAA800_tag Price: £3.10 | |
|
1.2V, 300 mAh, impedance 35 mOhm, up to 1000 cycles, weight 8.0 g, diameter 11 mm, height 28 mm. | ||
|---|---|---|
| |
NH-2/3AAA300_tag Price: £3.00 | |
Button tagged cells (Industrial Ni-MH)
|
3.6V, 150 mAh, up to 1000 cycles, weight 18 g, width 25.6 mm, length 17.7 mm, height 14.1 mm. Snap-on plastic casing. | ||
|---|---|---|
|
3-V150H_pin Price: £9.99 | |
|
4.8V, 150 mAh, up to 1000 cycles, weight 26 g, width 28 mm, length 17.7 mm, height 14.1 mm. Snap-on plastic casing. | ||
|---|---|---|
|
4-V150H_pin Price: £10.99 | |
|
6.0V, 150 mAh, up to 1000 cycles, weight 32 g, width 35 mm, length 17.7 mm, height 14.1 mm. Snap-on plastic casing. | ||
|---|---|---|
|
5-V150H_pin Price: £14.99 | |
|
2.4V, 150 mAh, up to 1000 cycles, weight 12.4 g, width 25.6 mm, length 11.8 mm, height 14.1 mm. Snap-on plastic casing. | ||
|---|---|---|
|
2-V150H_pin Price: £9.99 | |
|
1.2V, 150 mAh, up to 1000 cycles, weight 6 g, width 25.6 mm, length 14.1 mm, thickness 7.1 mm. | ||
|---|---|---|
|
1-V150H_pin Price: £5.99 | |
|
1.2V, 80 mAh, up to 1000 cycles, weight 12.4 g, diameter 15.5 mm, length 6 mm. Shrink wrap casing. Polarized 3 pins. | ||
|---|---|---|
|
1-V80H_pin Price: £3.50 | |
|
2.4V, 80 mAh, up to 1000 cycles, weight 12.4 g, diameter 16.5 mm, length 12 mm. Snap-on plastic casing. | ||
|---|---|---|
|
2-V80H_pin Price: £9.99 | |
|
3.6V, 80 mAh, up to 1000 cycles, weight 12.4 g, diameter 16.5 mm, length 18.3 mm. Shrink wrap casing. | ||
|---|---|---|
|
3-V80H_pin Price: £9.99 | |
|
1.2V, 20 mAh, up to 1000 cycles, weight 0.9 g, diameter 11.5 mm, thickness 2.2 mm. | ||
|---|---|---|
|
V20HR_tag Price: £3.99 | |
|
1.2V, 300 mAh, up to 1000 cycles, weight 12.4 g, diameter 25.1 mm, thickness 7.5 mm. Snap-on plastic casing. | ||
|---|---|---|
|
CP300H_tag Price: £4.99 | |
|
1.2V, 450 mAh, up to 1000 cycles, weight 14.5 g, length 34.1 mm, width 24.1 mm, thickness 5.1 mm. Shrink wrap insulation. | ||
|---|---|---|
|
V450HR_tag Price: £5.99 | |
|
1.2V, 600 mAh, up to 1000 cycles, weight 14.5 g, length 34.1 mm, width 24.1 mm, thickness 6.8 mm. Shrink wrap insulation. | ||
|---|---|---|
|
V600HR_tag Price: £5.99 | |
Prismatic
|
8.4v, 300mAh up to 1000 cycles, weight 56 g, dimensions 17.1 x 25.7 x 48.2 mm. | ||
|---|---|---|
|
NH-9V300 Price: £6.10 | |
|
8.4v, 160mAh up to 1000 cycles, weight 43 g, dimensions 17.0 x 25.8 x 48.1 mm. | ||
|---|---|---|
|
NH-9V160 Price: £4.99 | |
Cylindrical Tagged Nickel-Cadmium
|
1.2v, 720mAh up to 1000 cycles, weight 18 g, diameter 14.5 mm, height 42.5 mm. Opposing tags. | ||
|---|---|---|
|
NC-4-5AA Price: £4.99 | ||
|
1.2v, 150mAh up to 1000 cycles, weight 8 g, diameter 14.5 mm, height 17.0 mm. | ||
|---|---|---|
|
NC-1-3AA Price: £4.99 | |
|
2.4v, 150mAh up to 1000 cycles, weight 16 g, diameter 14.5 mm, height 34.0 mm. | ||
|---|---|---|
|
NC-2-3AA_tag Price: £4.99 | |
|
1.2V, 1700 mAh, impedance 80 mOhm, up to 1000 cycles, weight 50.0 g, diameter 23 mm, height 43 mm. | ||
|---|---|---|
|
|
NC-SC1700_tag Price: £6.99 | |
Make your own tagged cells (Wire Glue)
|
wire-glue A highly conductive glue.Simply stir and apply the glue to your surface and let it cure overnight. More details....... | ||
|---|---|---|
|
Wire-Glue £5.00 each. (£4.50 each if you buy two or more. Postage and packing included).
| |
