BR316 3V Lithium Pin Type Cell


Type: Lithium Carbon monofluoride (Li CFx). Notional Voltage: 3 V.

Length: 22.5 mm. Diameter: 3.0 mm.

Compatibility: Typical applications are powering LEDs for night fishing, flashing jewellery etc

Price: 2.50 each. 2.22 each if you buy two or more. Postage and packing included.

This BR316 3V Lithium battery uses the Lithium Carbon Monofluoride chemistry.

This BR316 3V 'pin type' lithium battery weighs about one fifth of a gram, the light weight achieved through the use of an aluminium canister.

This BR316 pin-type lithium battery is widely used in illuminated fishing floats for night fishing, PDA stylus with light source, miniature torches.


Light weight with aluminium case
High voltage compared with alkaline cells
Very small size
Family of three cells
Tolerates high and low temperature operation (-20 deg C to +60 deg C).


BR 316

Model Capacity (mAh) Weight (g) Dimensions (mm)
BR316 13 0.22 3 x 16

Self discharge is low at less than 0.5% per annum at 20C, giving an effective shelf life of 10 years.

With such a long shelf life, why not buy two or more packs of the BR316. Take advantage of our reduced price and make sure you are not left in the lurch next time your battery runs out.

This cell is available pre-fitted with a LED. Contact us for details.

Take a look at our full range on pin cells including 4mm pin cells that are not pre-fitted with LEDs such as the BR435.

* Actual manufacturer may vary depending upon availability
